| View Original: | TSOP-56 (T1) BW.svg (680x415) | |||
| Download: | Original | Medium | Small | Thumb |
| Courtesy of: | commons.wikimedia.org | More Like This | ||
| Keywords: TSOP-56 (T1) BW.svg An outline drawing of a Type 1 TSOP-56 IC Carrier Own drawing modelled in Solid Edge 14 exported to SVG 2007-05-28 Inductiveload TSOP-56 Coloured Drawing prettytable colspan 2 Image IC Carrier Icon svg Integrated Circuit Carrier - colspan 2 TSOP-56 Type 1 - Type Thin Small Outline Package - JEITA Code P-TSOP 1 -056-1420-0 50 - Number of Leads 56 - Type of Lead Gull-wing - Mounting Surface-mount - Nominal Body Width 14 mm - Nominal Body Length 18 4 mm - Nominal Overall Length 20 mm - Mounted Height 1 mm - Lead Pitch 0 50 mm Solid Edge drawings TSOP integrated circuit packages Line drawings of integrated circuits | ||||
