Keywords: Recursive raytracing.svg Idea of recursive raytracing Idea of recursive raytracing The sample 3D scene has two lights and 3 objects a - oval nontransparent nonreflecting b - sphere transparent and reflecting c - cube nontransparent but reflecting Observer camera is placed at point O Primary ray green is emited from O and hits object b Since this object reflects and refracts light two secondary rays are emitted from hit point red for reflected and blue for refracted ray Reflected ray hits object a and none secondary rays are emitted Refracted ray hits object b and is refracted one more time reflected ray hasn't been show however it should be emitted too This ray hit object c and just one reflected ray is emitted It do not hit any object and recursion stops Thin dashed lines are shadow rays - additional rays use to determine visibility of light object b occlude light L1 when point on b is shading when point on a is shading object blocks light L1 Computer graphics Ray tracing Shading |
