MAKE A MEME View Large Image Fixed Diff B.svg validSVG A fixed differential gear system This arrangement has a typical ratio of between 15 1 and 100 1 The ratio is given by <math>m_G \frac N_ R2 N_ P1 N_ R2 N_ P1 -N_ R1 N_ P2 </math> where <math>N_ R1 </math> is the ...
View Original:Fixed Diff B.svg (375x450)
Download: Original    Medium    Small Thumb
Courtesy of:commons.wikimedia.org More Like This
Keywords: Fixed Diff B.svg validSVG A fixed differential gear system This arrangement has a typical ratio of between 15 1 and 100 1 The ratio is given by <math>m_G \frac N_ R2 N_ P1 N_ R2 N_ P1 -N_ R1 N_ P2 </math> where <math>N_ R1 </math> is the number of teeth on the No 1 Ring gear R1 yellow <math>N_ R2 </math> is the number of teeth on the No 2 Ring gear R2 green <math>N_ P1 </math> is the number of teeth on the No 1 Planet gear P1 dark blue on the left <math>N_ S2 </math> is the number of teeth on the No 2 Planet gear P2 dark blue on the right The fixed member is the No 1 Ring the input member is the Planet Carrier PC red and the output member is the No 2 Ring self-made Inkscape 2008-03-18 Inductiveload Differential gear systems Drawings of gears and gearboxes Planetary gearing Transmissions SVG machinery
