| View Original: | Dipole receiving antenna animation 2 800x403x15ms.gif (800x403) | |||
| Download: | Original | Medium | Small | Thumb |
| Courtesy of: | commons.wikimedia.org | More Like This | ||
| Keywords: Dipole receiving antenna animation 2 800x403x15ms.gif dipole antenna receiving power from a radio wave The antenna consists of two metal rods each one-quarter of the wavelength long attached through a parallel transmission line to a resistance equal to the characteristic impedance of the antenna representing the receiver The electromagnetic wave coming from the right is represented by its electric field <span style color green; >E green arrows</span> it should be kept in mind that the drawing only shows the field along one line while the radio wave is actually a plane wave and the electric field is actually the same at every point on a plane perpendicular to the direction of motion The wave's magnetic field is not shown <br/><br/> The oscillating electric field exerts force on the electrons in the antenna rods black arrows causing them to move back and forth between the ends of the antenna rods charging the ends of the antenna alternately positive + and negative ˆ’ Since the antenna is a half-wavelength long at the radio wave's frequency it excites standing waves of voltage <span style color red; >V red</span> and current in the antenna The voltage along the antenna elements is represented graphically by a band of red whose thickness at any point is proportional to the magnitude of the voltage The waves of radio frequency voltage and current travel down the transmission line and are absorbed in the resistor In this animation the action is shown slowed down drastically; the radio waves received by dipoles actually oscillate back and forth at tens of thousands to billions of cycles per second 2015-05-29 own Chetvorno other versions Dipole receiving antenna animation 6 800x394x150ms gif - more closeup view<br/> Dipole_receiving_antenna_animation_4_616x380x150ms gif - shows waves of voltage and current traveling down transmission line cc-zero Uploaded with UploadWizard Dipole antennas Animated GIF Animations of vibrations and waves Animations of electronics | ||||
