| Keywords: Dab295.jpeg Mobile Alabama Region USGS map with KYMAK overlay Mobile Alabama KYMAK Comprehensive Regional Master Plan Details on Summary page The Mobile Region map is a part of a larger regional plan The straight orange line is in the major zone of development which extends to New Orleans and points beyond The irregular brown line shows expected continuous growth proposed in 1965 of the City of Mobile; the dotted green line is the current Mobile city limits KYMAK overlay for an orderly and systematic plan Municipal units are about 12 miles square the size of four townships and are laid out on a bias to avoid confusion with other survey lines; thus oriented it is an economy toward building life extension Unit perimeters are rights-of-ways reserved as open space for major transportation routes which can be developed as the need arises The Mo del-city shown at the top right can be adapted to any unit but would apply only to new development particularly of streets and subdivisions; old development remains as long as it is useful or desirable - yellow zone is suburban based on Frank Lloyd Wright's Broadacre City concept blue is residential green is agricultural the red square is the executive compound; the orange is the urban core dotted green is public land for wild-life preservation Suggested population densities and distribution and other details are on the KYMAK Model City page 2013-01-25 own MyName Dab295 <span class signature-talk >talk</span> 17 05 25 January 2013 UTC Cc-zero Maps of Alabama | ||||
