| Keywords: CentrifugalCompressor.jpg A single stage centrifugal compressor left driven by an electric motor right through a gearbox center A low-speed coupling connects the motor to the gearbox and a high-speed coupling connects the gearbox to the compressor Process gas enters the compressor through the flanged opening at left center and is discharged through the flange in the upper left corner of the photograph The impeller can be seen just inside the inlet port Figure 34 21 in Handbook for Notification of Exports to Iraq Annex 3 United Nations Security Council Resolution 1051 1996 prepared by the U S Department of Energy Nuclear Transfer and Supplier Policy Division http //www iraqwatch org/government/ 1996 UN document USGOV PD-USGov Centrifugal compressors | ||||
